Premium Oak Sliding Door System with Fixed End Panel
The Premium Oak Easi-frame system is the ideal solution for dividing rooms while maintaining an open-plan atmosphere. Replace solid walls with folding or sliding doors to create an illusion of space and enhance comfortable living.
These sliding French doors are designed to slide along a track, saving space as they do not require clearance to open like traditional French doors. The Easi-frame can accommodate almost any door design and is suitable for openings up to 3500mm wide.
Style your space by mixing and matching between glazed and non-glazed doors, allowing for complete customization of your design.
The overall frame height is 2090mm, allowing for a 21mm floor covering. If the frame is installed over an existing floor covering, the height must be reduced to 2069mm.
- Complete with all necessary sliding hardware, excluding the handle.
- Includes doors and fixed panels.
- Frame can be resized in height and width for various opening sizes.
- Flush installation with floor level possible if the floor channel is in place before floor covering.
- Engineered construction ensures added strength, stability, and performance.
- Product is supplied unfinished, ready for painting or staining.
Size Options
| Door Size | Overall Size Including Frame |
|---|---|
| 1 x 762mm Door + 762mm Fixed Panel | 2090mm x 1584mm |
| 1 x 838mm Door + 838mm Fixed Panel | 2090mm x 1736mm |
The Easi-Slide Frame is a versatile product designed for installers to adapt to various sizes and opening configurations. It is the responsibility of the installer to ensure the proper dimensions and assembly for the intended use. Always dry assemble before cutting any openings to ensure accuracy.
Technical Specifications
- Suitable for standard 35mm thick doors; fire doors are not compatible.
- Unfinished product allows for customization with paint or stain.
FAQ
- Can I use fire doors with this system? No, the system is only compatible with standard 35mm thick doors.
- What is the maximum opening size? The system accommodates openings up to 3500mm wide.
- Can I install the frame flush with the floor? Yes, provided the floor channel is installed before the floor covering.
