Premium Oak Bifolding Doorset - Unfinished Design for Seamless Room Transitions in Multiple Configurations

Transform Your Home with a Premium Oak Bifolding Doorset

Enhance your living space with the elegant and versatile Premium Oak Bifolding Doorset. This traditional design in unfinished oak offers a charming addition to any interior, creating a seamless flow between rooms while maintaining style and functionality.

The bifolding doorset is available in three configurations and three door sizes: a 3-leaf, 4-leaf, and 5-leaf system. The frame is supplied complete with the top track, top pivot, apron plate, bottom pivot, and chrome hinges. Notably, there is no bottom frame or floor guide included with this doorset, allowing flooring to continue uninterrupted between rooms.

Doors are supplied unfinished, requiring priming and painting on-site to achieve your desired look.

Installation Notes

• No bottom frame is required; this system is top-hung only.
• Maximum trimming allowed on each door edge is 5mm.
• Doors are supplied unfinished and ready for onsite finishing.
• Available in three widths: 533mm, 610mm, and 686mm.
• The folding frame is also supplied unfinished and ready for final finishing.

Door Size Options

The Premium Bifolding Doorset is available in the following size options:

• 533mm
• 610mm
• 686mm

Note: External frame measurements will be 10mm smaller in height and width.

Structural Opening Sizes

Configurations (Structural Opening Size with 533mm Doors)

• 3+0 Configuration with 3x21" Doors - Overall Size: 2083mm x 1681mm
• 3+1 Configuration with 4x21" Doors - Overall Size: 2083mm x 2214mm
• 4+1 Configuration with 5x21" Doors - Overall Size: 2083mm x 2747mm

Configurations (Structural Opening Size with 610mm Doors)

• 3+0 Configuration with 3x24" Doors - Overall Size: 2083mm x 1912mm
• 3+1 Configuration with 4x24" Doors - Overall Size: 2083mm x 2522mm
• 4+1 Configuration with 5x24" Doors - Overall Size: 2083mm x 3132mm

Configurations (Structural Opening Size with 686mm Doors)

• 3+0 Configuration with 3x27" Doors - Overall Size: 2083mm x 2140mm
• 3+1 Configuration with 4x27" Doors - Overall Size: 2083mm x 2826mm
• 4+1 Configuration with 5x27" Doors - Overall Size: 2083mm x 3512mm

Please be aware that these sizes are based on the subfloor level. If you plan to install the frames on top of a floor covering, adjustments may be necessary.

Technical Specifications

FAQs

• Do I need to finish the doors? Yes, the doors are supplied unfinished and require on-site finishing.
• What is the maximum trimming allowed? Up to 5mm can be trimmed from each door edge.
• Is a bottom frame required? No, this bifolding system is designed to be top-hung only.
