Product Overview
This Premium Fire Rated Pocket Door System is supplied complete with a white extra slim fire door. This system allows you to slide the door straight into a discreet pocket, which is hidden within the cavity. The pocket frame is constructed from galvanised steel and is supplied complete with the necessary track and fixings. The cassette system includes a comprehensive timber lining kit (jambs) to ensure a perfect installation.
The door jambs are 100mm, and for 3" studwork, you would require 100mm jambs to achieve a finished wall thickness of 100mm when finished with 12.5mm plasterboard.
There is no bottom track or threshold strip; similar to all pocket door systems, the single pocket door frame is top hung from a track. Inside the track, there are runners attached to the top of the door via a bracket, allowing for a seamless flooring transition through the opening without disturbance. Accessories such as soft door closers, flush door pulls, and bathroom locks can be purchased separately.
Door Specifications
- Custom made to your requirements
- 15mm Extra Slim Rails
- 100mm Stile Size (Outer Edge)
- FD30 - 30 Minutes Fire Rating
- Clear Fire Glass
- Obscure Fire Glass Available
- Supplied White Primed Ready for Final Finish
- Matching Frame Available
- Black VP intumescent seals
- Available in 4L Design
- Matching Double Doors Also Available
Set Includes
- Custom Made White Extra Slim Fire Door
- FD30 - 30 Minutes Fire Rated Door System
- 100mm Jambs (wall thickness)
- 44mm Thick Door
- Strong galvanised steel frame; a quick-click frame that assembles into a complete unit comprising a full pocket and track.
- Runners tested to 100,000 cycles (approximately 25 years of average use)
- Adjustable to determine how far the door protrudes from the pocket.
- Jamb kit made from finger jointed fir, unfinished and ready to paint/stain.
- Door guide slots into a channel on the underside of the door; this feature ensures smooth sliding even if the door warps.
- 15-year guarantee on the complete pocket door system and runners.
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Width | 610mm - 762mm |
| Height | 1981mm |
| Pocket Frame Dimensions | 1273 x 2056 mm, 1449 x 2056 mm, 1625 x 2056 mm |
FAQ
What is the fire rating of this door system?
The door system has an FD30 fire rating, providing 30 minutes of fire resistance.
Can I customize the dimensions of the door?
Yes, the door is custom made to your requirements.
What is the warranty on this pocket door system?
There is a 15-year guarantee on the complete pocket door system and runners.
