Premium Fire Rated Pocket Door System with 4 Panel Design and Galvanised Steel Frame for Seamless Installation
Premium Fire Rated Pocket Door System with 4 Panel Design and Galvanised Steel Frame for Seamless Installation
Product Overview
This Premium Fire Rated Pocket Door System is designed to provide a seamless and stylish entry solution. It comes complete with a 4 Panel Fire Door, allowing you to slide the door directly into a discreet pocket hidden within the wall cavity. The pocket frame is constructed from durable galvanised steel and includes the track and necessary fixings for straightforward installation.
The system also features a comprehensive timber lining kit (jambs) to ensure a perfect finish. The door jambs have a thickness of 100mm, which is ideal for use with 3" studwork, resulting in a finished wall thickness of 100mm when covered with 12.5mm plasterboard.
Notably, there is no bottom track or threshold strip. This innovative pocket door system is top-hung from a track, featuring runners attached to the top of the door via a bracket. This design allows for uninterrupted flooring throughout the opening. Optional accessories such as soft door closers, flush door pulls, and bathroom locks are available for separate purchase.
Key Features
- Compatible with 44mm FD30 rated fire doors
- FD30 - 30 Minutes Fire Rated Door System
- 44mm Thick Fire Door
- Strong galvanised steel frame with a quick-click assembly
- Runners tested for up to 100,000 cycles, equating to approximately 25 years of average use
- Adjustable door protrusion from the pocket
- Jamb kit made from finger-jointed fir, unfinished and ready for painting or staining
- Door guide slots into a channel on the underside of the door, ensuring smooth operation even if the door warps
- 15-year guarantee on the complete pocket door system and runners
Dimensions & Specifications
| Door Panel Size (Width x Height) | Pocket Frame Size (Width x Height) |
|---|---|
| 610 x 1981 mm | 1273 x 2061 mm |
| 686 x 1981 mm | 1449 x 2061 mm |
| 762 x 1981 mm | 1625 x 2061 mm |
| 838 x 1981 mm | 1701 x 2061 mm |
| 626 x 2040 mm | 1288 x 2120 mm |
| 726 x 2040 mm | 1488 x 2120 mm |
| 826 x 2040 mm | 1688 x 2120 mm |
| 926 x 2040 mm | 1888 x 2120 mm |
FAQ
- What is the fire rating of this door system? The door system is rated FD30, providing 30 minutes of fire resistance.
- Can I use this pocket door system with any wall thickness? It is designed for use with a 100mm wall thickness when using 12.5mm plasterboard.
- What kind of accessories are available? Accessories include soft door closers, flush door pulls, and bathroom locks.
