Premium Extra Slim 4L Fire Rated Pocket Door System with Galvanised Steel Frame and Custom Made Options
Premium Extra Slim 4L Fire Rated Pocket Door System with Galvanised Steel Frame and Custom Made Options
Product Overview
This Fire Pocket Door System is supplied complete with a white extra slim fire door. The system allows the door to slide directly into a discreet pocket hidden within the cavity. The pocket frame is constructed from galvanised steel and is supplied complete with the track and fixings. The cassette system includes a comprehensive timber lining kit (jambs) to ensure perfect installation.
The door jambs measure 100mm, and for 3" studwork, 100mm jambs are required to achieve a finished wall thickness of 100mm when finished with 12.5mm plasterboard.
This system has no bottom track or threshold strip; the frame is top hung from a track. Inside the track, runners are attached to the top of the door via a bracket. This design means there's no visible track on the floor, allowing for uninterrupted flooring continuation through the opening. Accessories such as soft door closers, flush door pulls, and bathroom locks are available for separate purchase.
Door Specifications
- Custom made to your requirements
- 15mm Extra Slim Rails
- 100mm Stile Size (Outer Edge)
- FD30 - 30 Minutes Fire Rating
- Clear Fire Glass
- Obscure Fire Glass Available
- Supplied White Primed Ready for Final Finish
- Matching Frame Available
- Black VP intumescent seals
- Available in 4L Design
- Matching Double Doors Also Available
Set Includes
- Custom Made White 4L Fire Door
- FD30 - 30 Minutes Fire Rated Door System
- 100mm Jambs (wall thickness)
- 44mm Thick Door
- Strong galvanised steel frame - a quick-click frame that assembles into a complete unit comprising a full pocket and track
- Runners tested to 100,000 cycles (approximately 25 years of average use)
- Adjustable door protrusion from the pocket
- Jamb kit made from finger jointed fir, unfinished and ready to paint/stain
- Door guide slots into a channel on the underside of the door, ensuring smooth operation even if the door warps
- 15-year guarantee on the complete pocket door system and runners
Overall Frame Dimensions with Fire Door
| Door Panel Size | Pocket Frame Dimensions (Width x Height) |
|---|---|
| 610 x 1981 | 1273 x 2056 mm |
| 686 x 1981 | 1449 x 2056 mm |
| 762 x 1981 | 1625 x 2056 mm |
Technical Specifications
- Material: Galvanised Steel Frame
- Fire Rating: FD30 - 30 Minutes
- Thickness: 44mm Door
- Jamb Thickness: 100mm
- Rail Thickness: 15mm
- Runners tested to 100,000 cycles
Frequently Asked Questions
1. Can the door be adjusted after installation?
Yes, the door can be adjusted to determine how far it protrudes from the pocket.
2. What is the fire rating of this pocket door?
This pocket door has a fire rating of FD30, providing up to 30 minutes of fire protection.
3. What materials make up the jamb kit?
The jamb kit is made from finger jointed fir and is supplied unfinished for painting or staining.
