Premium Extra Slim Cross Bar Fire Rated Pocket Door System with Galvanised Steel Frame and Adjustable Features
Premium Extra Slim Cross Bar Fire Rated Pocket Door System with Galvanised Steel Frame and Adjustable Features
Product Overview
This Premium Fire Pocket Door System is supplied complete with an Industrial Style Cross Bar Fire Door designed for seamless integration into your space. The door slides into a discreet pocket hidden within the cavity, providing a clean and modern look.
The pocket frame is constructed from durable galvanised steel and comes complete with a track and fixings. The system includes a comprehensive timber lining kit (jambs) to ensure a perfect finish during installation.
With no bottom track or threshold strip, the door frame is top hung from a track, allowing your flooring to continue uninterrupted through the opening. Optional accessories such as soft door closers, flush door pulls, and bathroom locks are available for separate purchase.
Door Specifications
- Custom made to your requirements
- 15mm Extra Slim Rails
- 100mm Stile Size (Outer Edge)
- FD30 - 30 Minutes Fire Rating
- Clear Fire Glass
- Obscure Fire Glass Available
- Supplied White Primed Ready for Final Finish
- Matching Frame Available
- Black VP intumescent seals
- Available in 4L Design
- Matching Double Doors Also Available
Set Includes
- Custom Made White Cross Bar Fire Door
- FD30 - 30 Minutes Fire Rated Door System
- 100mm Jambs (wall thickness)
- 44mm Thick Door
- Strong galvanised steel frame with quick-click assembly for a complete pocket and track unit
- Runners tested to 100,000 cycles (approximately 25 years of average use)
- Adjustable door protrusion from the pocket
- Jamb kit made from finger jointed fir, unfinished and ready to paint/stain
- Door guide slots into a channel on the underside of the door for smooth operation
- 15-year guarantee on the complete pocket door system and runners
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| 610 x 1981 Door Panel | 1273 x 2056 mm Pocket Frame |
| 686 x 1981 Door Panel | 1449 x 2056 mm Pocket Frame |
| 762 x 1981 Door Panel | 1625 x 2056 mm Pocket Frame |
Technical Specifications
- Material: Galvanised Steel Frame
- Fire Rating: FD30 - 30 Minutes
- Thickness: 44mm Door
- Rail Size: 15mm Extra Slim
- Jamb Size: 100mm
- Guarantee: 15 years on the complete system
Frequently Asked Questions
1. Can the door be customized?
Yes, the door is custom made to your specific requirements.
2. What is the fire rating of this door system?
The door system has a fire rating of FD30, providing 30 minutes of fire resistance.
3. How long is the guarantee?
The complete pocket door system and runners come with a 15-year guarantee.
