Premium Tongue and Groove External Fire Door Set with Sidelight - 30 Minute Fire Resistance, Durable GRP Core, Multipoint Locking System
Premium Tongue and Groove External Fire Door Set with Sidelight - 30 Minute Fire Resistance, Durable GRP Core, Multipoint Locking System
Product Overview
This premium tongue and groove external fire door set with sidelight is designed to meet rigorous fire safety standards while providing durability and security. The door features a solid-core construction made of glass-reinforced plastic (GRP), offering half-hour fire resistance to BS 476 part 22 and smoke resistance to BS 476 part 31:1.
The set is complete with a frame and ironmongery, ready for installation. For external use as a main door, ensure compliance with regulations by selecting the 'secure by design' option if a letter plate is required.
Non-Secured By Design Features
- White PVC Fire-check Frame
- Multipoint Locking System
- Overhead Closer Fitted as Standard
- Fire Rated Hinges
- Choice of 11 Colours for the External Face
- White Internal Face
- Door Handle Included - Choose from Silver or Brass Finish
Secured by Design Doorsets Features
- Door Leaf Type: Solid timber core
- Choice of 11 Colours for the External Face
- Outer Frame Type: White PVCu extruded
- Intumescent Seals: Applied to the top and bottom of the door leaf, to the internal rebate and outside of the outer frame
- Threshold: Slimline with fire retardant seal ·Low Mobility compliant
- Timber Cill Options
- Timber-like Grained Finish
- Hinges: 4 Nico Lift-off Hinges
- Lock: 4 Point Autofire Locking System with Adjustable Keeps
- Cylinder: 3* Key-Thumb Turn Cylinder, with 3 Keys
- Handle: Lever-Lever
- Viewer: 180 Degrees Fire-Rated Viewer (optional)
- Knocker: Urn Knocker (optional)
- Letter Plate: Fire-Rated TS008 Letter Plate with Integral Cowl (optional)
- Closer: Overhead Closer Model TS5204
- Security Chain: Hook Type (optional)
- Hardware Finish: Gold or Silver
Sidelight Features
- PVC Framed Glazed Sidelight
- Fire Rated Glass
- Available with Clear or Obscure (Stippolyte) Glass
- Sidelights Available in Three Widths: 250mm, 400mm, 600mm
Certification and Accreditations
- Fire Tested to: BS 476: Part 20/22:1987 EN 1634-1: 2014 + A1:2018. All door sets are bi-directionally tested.
- Smoke Control Certified
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Fire Resistance | 30 Minutes |
| Sidelight Widths | 250mm, 400mm, 600mm |
FAQ
Q: What is the fire resistance rating of this door?
A: The door has a fire resistance rating of 30 minutes.
Q: Can I customize the color of the external face?
A: Yes, you can choose from 11 different colors for the external face.
Q: What are the sidelight options available?
A: The sidelights can be fitted with clear or obscure fire rated glass and come in three widths.
