Premium External Fire Doorset with Sidelight - 30 Minute Fire Resistance, Durable GRP Solid-Core Design with Various Color Options

Product Overview

This Premium External Fire Doorset with Sidelight is designed to meet rigorous fire safety standards while providing durability and security. Constructed with a solid-core design, this fire door boasts a half-hour fire resistance as per BS 476 part 22 and offers resistance to smoke passage per BS 476 part 31:1.

The doorset comes complete with a frame and ironmongery, making it ready to install into your opening. For external doors that require a letter plate, please select the 'secure by design' option to comply with current regulations.

Features

The Premium External Fire Doorset can be customized to suit your needs, featuring:

• Non-Secured By Design Includes:
• White PVC Fire-check Frame
• Multipoint Locking System
• Overhead Closer Fitted as Standard
• Fire Rated Hinges
• Choice of 11 Colours for the External Face
• White Internal Face
• Door Handle Included Choose from Silver or Brass finish
• Secured by Design Doorsets Include:
• Door Leaf Type: Solid timber core
• Choice of 11 Colours for the External Face
• Outer Frame Type: White PVCu extruded
• Intumescent Seals: Applied to the top and bottom of the door leaf, to the internal rebate and outside of the outer frame, and selected components
• Threshold: Slimline with fire retardant seal ·Low Mobility compliant
• Timber Cill options
• Timber-like grained
• Hinges: 4no Nico Lift off hinges
• Lock: ERA Surefire 4 point autofire locking system with adjustable keeps
• Cylinder: 3* Key-thumb turn cylinder, with 3 keys
• Handle: Lever-lever
• Viewer: 180 degrees fire-rated viewer (optional)
• Knocker: Urn knocker (optional)
• Letter plate: Fire-rated TS008 Letter plate with integral cowl (optional)
• Closer: Rutland TS5204 overhead closer
• Security Chain: Hook type (optional)
• Hardware finish: Gold or Silver

Sidelight Features

• PVC framed glazed sidelight
• Fire rated glass
• Available with Clear or Obscure (Stippolyte) glass
• Sidelights available in three widths: 250mm, 400mm, 600mm

Certification and Accreditations

• Fire tested to: BS 476: Part 20/22:1987, EN 1634-1: 2014 + A1:2018. All door sets are bi-directionally tested
• Smoke Control test: EN 1634-3: 2004
• CE Marking: External ·Yes
• PAS 24 / Secured By Design: PAS 24 2016

Dimensions & Specifications

FAQs

• What is the fire resistance rating? The doorset has a fire resistance rating of 30 minutes.
• Can I customize the color of the doorset? Yes, there are 11 color options available for the external face.
• Is the sidelight included? Yes, the sidelight comes with fire rated glass and is available in various widths.
