Premium External Fire Doorset with Sidelight - 30 Minute Fire Resistance, Multipoint Locking System, and Thermal Efficiency

Product Overview

This Premium External Fire Doorset with Sidelight is designed to perform under the rigorous demands of fire safety. With a 30-minute fire resistance rating according to BS 476 part 22 and smoke resistance to BS 476 part 31:1, this doorset offers unparalleled durability and security.

The doorset is supplied complete with a sturdy frame and ironmongery, making it ready to hang in your opening. It is ideal for use as the main external door, especially when used in conjunction with a letter plate for compliance with current regulations.

Features

• Fire Resistance: 30 minutes with GRP solid-core construction.
• Smoke Resistance: Compliant with BS 476 part 31:1.
• Multipoint Locking System: Enhanced security features.
• Maintenance-Free: Glass-reinforced door sets with high thermal efficiency.

Non-Secured By Design Features

• White PVC Fire-check Frame
• Multipoint Locking System
• Overhead Closer Fitted as Standard
• Fire Rated Hinges
• Choice of 11 Colours for the External Face
• White Internal Face
• Door Handle Included: Choose from Silver or Brass finish

Secured by Design Features

• Door Leaf Type: Solid timber core
• Choice of 11 Colours for the External Face
• Outer Frame Type: White PVCu extruded
• Intumescent Seals: Applied to the top and bottom of the door leaf, to the internal rebate, and outside of the outer frame.
• Threshold: Slimline with fire retardant seal ·Low Mobility compliant
• Timber Cill options available
• 4 Nico Lift off hinges
• ERA Surefire 4 point autofire locking system with adjustable keeps
• 3* Key-thumb turn cylinder, with 3 keys
• Lever-lever handle
• 180 degrees fire-rated viewer (optional)
• Urn knocker (optional)
• Fire-rated TS008 Letter plate with integral cowl (optional)
• Rutland TS5204 overhead closer
• Hook type security chain (optional)
• Hardware finish: Gold or Silver

Sidelight Specifications

• PVC framed glazed sidelight
• Fire rated glass available in Clear or Obscure (Stippolyte)
• Sidelights available in three widths: 250mm, 400mm, 600mm

Certification and Accreditations

• Fire tested to: BS 476: Part 20/22:1987 EN 1634-1: 2014 + A1:2018. All door sets are bi-directionally tested.
• Smoke Control test: EN 1634-3: 2004
• CE Marking: External ·Yes
• PAS 24 / Secured By Design: PAS 24 2016 compliant

Dimensions & Specifications

FAQ

What fire rating do these doorsets have?

The doorsets are rated for 30 minutes of fire resistance.

Can I choose the color of the external face?

Yes, there is a choice of 11 colors for the external face.

Are the sidelights available in different sizes?

Yes, sidelights are available in widths of 250mm, 400mm, and 600mm.
