Premium Oak Tongue and Groove External Fire Door Set with Sidelight - 30 Minute Fire Resistance and Versatile Color Options

Product Overview

This Premium Oak Tongue and Groove External Fire Door Set with Sidelight is designed to meet the rigorous demands of a fire door, ensuring safety and security. Featuring a robust solid-core construction, this door set offers a half-hour fire resistance compliant with BS 476 part 22, as well as smoke resistance per BS 476 part 31:1.

Our door set includes a complete frame and ironmongery, making it ready to install in your opening. It is also available in both 30 and 60-minute timber doors that bear the Kitemark (PAS 23 AND 24), ensuring compliance with safety standards while providing excellent thermal efficiency.

Key Features

• 30-minute fire resistance rating
• Solid-core construction for durability and security
• Half-hour fire resistance to BS 476 part 22
• Smoke resistance to BS 476 part 31:1
• Includes frame and ironmongery for easy installation

Non-Secured By Design Includes:

• White PVC Fire-check Frame
• Multipoint Locking System
• Overhead Closer Fitted as Standard
• Fire Rated Hinges
• Choice of 11 Colors for the External Face
• White Internal Face
• Door Handle Included (Choose from Silver or Brass finish)

Secured by Design Doorsets Include:

• Door Leaf Type: Solid timber core
• Choice of 11 Colors for the External Face
• Outer Frame Type: White PVCu extruded
• Intumescent Seals: Applied to enhance fire resistance
• Threshold: Slimline with fire retardant seal ·Low Mobility compliant
• Timber Cill options available
• Timber-like grained finish
• Hinges: 4 Nico Lift-off hinges
• Lock: ERA Surefire 4-point autofire locking system with adjustable keeps
• Cylinder: 3* Key-thumb turn cylinder, with 3 keys
• Handle: Lever-lever
• Viewer: 180 degrees fire-rated viewer (optional)
• Knocker: Urn knocker (optional)
• Letter plate: Fire-rated TS008 Letter plate with integral cowl (optional)
• Closer: Rutland TS5204 overhead closer
• Security Chain: Hook type (optional)
• Hardware finish: Gold or Silver

Sidelight Features

• PVC framed glazed sidelight
• Fire rated glass
• Available with Clear or Obscure (Stippolyte) glass
• Sidelights available in three widths: 250mm, 400mm, and 600mm

Certification and Accreditations

• Fire tested to: BS 476: Part 20/22:1987, EN 1634-1: 2014 + A1:2018
• All door sets are bi-directionally tested

Dimensions & Specifications

Frequently Asked Questions

• What is the fire resistance rating of this door?
  This door has a fire resistance rating of 30 minutes.
• Can I choose different colors for the external face?
  Yes, there is a choice of 11 colors available for the external face.
• Is the sidelight included with the door set?
  Yes, the sidelight comes with fire-rated glass and is available in various widths.
