Premium External Fire Door Set with 30-Minute Fire Resistance, Multipoint Locking System, and Customizable Color Options

Product Overview

This Premium External Fire Door Set is designed to perform and meet rigorous fire door demands. Featuring a solid-core construction, this door provides unparalleled durability and security with a half-hour fire resistance to BS 476 part 22 and smoke resistance to BS 476 part 31:1.

Our range also offers 30 and 60-minute timber doors compliant with the Kitemark (PAS 23 and 24). These versatile glass-reinforced door sets are maintenance-free and meet mandatory requirements while providing excellent thermal efficiency. Supplied complete with frame and ironmongery, this door set is ready to hang into your opening.

Features

• Half-hour fire resistance rating
• Solid-core construction for enhanced durability
• Available in a choice of 11 colors for the external face
• Includes multipoint locking system for added security
• Overhead closer fitted as standard
• Fire-rated hinges for safety
• White PVC fire-check frame
• Door handle options in silver or brass finish

Options Available

If the fire door is used as the main external door and requires a letter plate, the "secure by design" option must be selected to comply with the latest regulations. Below are the two configurations available:

Non-Secured By Design Includes:

• White PVC Fire-check Frame
• Multipoint Locking System
• Overhead Closer Fitted as Standard
• Fire Rated Hinges
• Choice of 11 Colours for the External Face
• White Internal Face
• Door Handle Included - Choose from Silver or Brass finish

Secured by Design Doorsets Include:

• Door Leaf Type: Solid timber core
• Choice of 11 Colours for the External Face
• Outer Frame Type: White PVCu extruded
• Intumescent Seals: Applied to the top and bottom of the door leaf, to the internal rebate, and outside of the outer frame
• Threshold: Slimline with fire retardant seal ·Low Mobility compliant
• Timber Cill options available
• Hinges: 4 Nico Lift off hinges
• Lock: 4 point autofire locking system with adjustable keeps
• Cylinder: Key-thumb turn cylinder with 3 keys
• Handle: Lever-lever
• Viewer: 180 degrees fire-rated viewer (optional)
• Knocker: Urn knocker (optional)
• Letter plate: Fire-rated TS008 letter plate with integral cowl (optional)
• Closer: Rutland TS5204 overhead closer
• Security Chain: Hook type (optional)
• Hardware finish options: Gold or Silver

Certification and Accreditations

• Fire tested to: BS 476: Part 20/22:1987, EN 1634-1: 2014 + A1:2018. All door sets are bi-directionally tested.
• Smoke Control test: EN 1634-3: 2004
• CE Marking: External ·Yes
• PAS 24 / Secured By Design: PAS 24 2016 specification and Secured by Design accredited
• All fire door sets meet current building regulations.

Technical Specifications

FAQ

• What is the fire resistance rating of this door set?
  The door set has a fire resistance rating of 30 minutes.
• Can I customize the color of the external face?
  Yes, you can choose from a selection of 11 colors for the external face.
• Is the door set compliant with building regulations?
  Yes, all fire door sets meet current building regulations.
