Premium Double Pocket Door System with Galvanised Steel Frame and Decorative Diamond Moulding for Timeless Design

Product Overview

Elevate your home with the Premium Double Pocket Door System, where timeless design meets unwavering quality. This architectural gem features a single bevelled panel adorned with captivating diamond moulding, positioned subtly below centre to create visual depth and interest. The decorative centre panel and carefully crafted inset profile bead deliver understated luxury. Built for longevity and designed to impress, this door system is the discerning choice for those who refuse to compromise between strength and style.

This double door system allows you to slide the doors straight into discreet pockets which are hidden within the cavity. The pocket frame is constructed from galvanised steel and is supplied complete with the track and fixings. The cassette system comes complete with a comprehensive timber lining kit (jambs) to finish the installation perfectly.

The door jambs are available in two size options: 100mm or 125mm. If using 3" studwork, you would require 100mm jambs for a finished wall thickness of 100mm when finished with 12.5mm plasterboard. If using 4" studwork, the 125mm jambs are necessary for an overall wall thickness of 125mm when using 125mm plasterboard.

There is no bottom track or threshold strip, as this pocket door system is top hung from a track. Inside the track, there are runners which are attached to the top of the doors via a bracket. This means there is no threshold strip or track on the floor, allowing your flooring to continue through the opening undisturbed. Accessories such as soft door closers, flush door pulls, and bathroom locks can all be purchased separately.

Key Features

• 35mm thick doors
• Strong galvanised steel frame with a quick-click assembly for a complete unit comprising of a full pocket and track
• Runners tested to 100,000 cycles (approximately 25 years of average use)
• Adjustable to determine how far the doors protrude from the pockets
• Jamb kit made from finger jointed fir, unfinished, ready to paint or stain
• Door guide slots into a channel on the underside of the doors, ensuring smooth operation even if the doors warp
• Maintenance-free track and runners
• 15-year guarantee on the complete steel pocket system and runners

Dimensions & Specifications

Technical Specifications

• Material: Galvanised Steel Frame
• Door Thickness: 35mm
• Runner Cycle Test: 100,000 cycles
• Jamb Kit Material: Finger Jointed Fir

FAQs

Q: What is the weight capacity of the pocket door system?
A: The system is designed for standard residential use, accommodating typical door weights.

Q: Are the jambs finished?
A: The jambs are unfinished and ready for painting or staining according to your preferences.

Q: How do I maintain the track and runners?
A: The track and runners are maintenance-free; no additional care is needed.
