Premium Double Door Co-Ordination Kit for Classic Pocket Systems with Soft Close Feature and Extractable Track

Co-ordination Kit for Double Door System

This Premium Double Door Co-Ordination Kit allows for synchronized opening and closing of two doors within a Classic Double Pocket System. When one door is opened or closed, the other follows suit, providing ease of access and convenience. This system is designed for retrofitting, thanks to its patented extractable track that can be removed, making installation straightforward for wooden doors only.

Product Features

• Can be retrofitted due to the extractable track.
• Compatible with the Classic Double Pocket Door System and Wiring Ready variants.
• Synchronized operation: open or close one door and the other will follow.
• Includes one soft close mechanism for doors weighing up to 20Kg each; additional soft close can be purchased for heavier doors.

Technical Specifications

Each co-ordination kit includes one soft close, which helps to slow down and close the doors gently if each door does not exceed 20Kg. For doors exceeding this weight, an additional soft close can be acquired. If using the co-ordination kit with the BIAS soft close, you will need two BIAS soft closes for doors over 20Kg, and one for those under this weight.

The system utilizes a specially developed cable for its robustness and stretch resistance. This cable consists of 132 strands with a diameter of 2mm, paired with a zinc-plated 1.5mm spring. The cable is securely attached to the door using a centrally installed bracket on the top of the door.

Frequently Asked Questions

1. Can this kit be installed on existing doors?

Yes, the co-ordination kit can be retrofitted to existing installations with the extractable track.

2. What is the maximum weight for doors using this system?

Each door can weigh up to 20Kg with the included soft close mechanism. For heavier doors, additional soft close mechanisms are recommended.

3. Is the cable included with the kit?

Yes, the kit includes a specially designed cable that is both strong and resistant to stretching.
