Premium Clear Glazed Bi-Folding Room Divider - Top Hung System with Multiple Configurations and Seamless Floor Finish
Premium Clear Glazed Bi-Folding Room Divider - Top Hung System with Multiple Configurations and Seamless Floor Finish
Stylish Room Divider Solution
A stylish room divider solution that uses a high-quality track, allowing doors to effortlessly fold and glide. This is the perfect solution for dividing two rooms while having the flexibility to create one large open space when required. Bi-folding doors offer a vast array of different options, enabling you to choose from numerous styles of doors in many finishes, allowing you to create the perfect harmonious space in your home.
Top Hung System (No Bottom Track)
Our folding systems are a complete off-the-shelf solution allowing you to quickly and easily install your chosen configuration. We have specially designed the track and bearings, putting them through rigorous testing to ensure they can withstand the weight of the doors from the top hangers. As there is no bottom track, you can continue the floor covering directly through from room to room. The high-quality mechanisms ensure that your doors will effortlessly slide every single time and will last for years to come.
Configurations (External Frame Dimensions with 610mm Doors)
| Configuration | Overall Size |
|---|---|
| 2+0 with 2x24" Doors | 2060mm x 1295mm |
| 2+1 with 3x24" Doors | 2060mm x 1908mm |
| 3+0 with 3x24" Doors | 2060mm x 1908mm |
| 3+1 with 4x24" Doors | 2060mm x 2521mm |
| 2+2 with 4x24" Doors | 2060mm x 2521mm |
| 4+0 with 4x24" Doors | 2060mm x 2521mm |
Configurations (External Frame Dimensions with 686mm Doors)
| Configuration | Overall Size |
|---|---|
| 2+0 with 2x27" Doors | 2060mm x 1447mm |
| 2+1 with 3x27" Doors | 2060mm x 2136mm |
| 3+0 with 3x27" Doors | 2060mm x 2136mm |
| 3+1 with 4x27" Doors | 2060mm x 2825mm |
| 2+2 with 4x27" Doors | 2060mm x 2825mm |
| 4+0 with 4x27" Doors | 2060mm x 2825mm |
Sliding Folding Mechanism
This bifold system is supplied complete with all fixings and sliding door gear. There is NO BOTTOM TRACK, so the doors are hung from the top hangers only, allowing a seamless floor finish. Please note that the measurements provided do not take into consideration any floor covering, so it is recommended to add the thickness of your floor covering to the overall size as needed.
Technical Specifications
- Material: High-quality wood
- Track Type: Top hung system
- Configurations available with multiple door sizes
Frequently Asked Questions
-
What is the benefit of a top hung system?
A top hung system allows for a seamless floor finish and easy sliding of doors. -
Are the doors customizable?
Yes, you can choose from a variety of styles and finishes to suit your space. -
Is installation complicated?
No, the system is designed for quick and easy installation.
