Premium Clear Glazed Pocket Door Set with Galvanised Steel Frame for Timeless Elegance and Space Efficiency
Premium Clear Glazed Pocket Door Set with Galvanised Steel Frame for Timeless Elegance and Space Efficiency
Product Overview
The Premium Clear Glazed Pocket Door Set brings timeless elegance to any home. Its distinctive vertical grain pattern delivers authentic rustic charm while the glazed side lite floods your entrance with natural light, perfect for contemporary interiors. This versatile choice adapts seamlessly to various architectural styles and room dimensions, making it ideal for homeowners seeking both character and practicality.
This door system allows you to slide the door straight into a discreet pocket hidden within the cavity. The pocket frame is constructed from galvanised steel and is supplied complete with the track and fixings. The cassette system comes with a comprehensive timber lining kit (jambs) to finish the installation perfectly.
Features and Benefits
- 35mm/40mm thick door supplied fully finished.
- Strong galvanised steel frame, a quick-click frame that assembles into a complete unit comprising a full pocket and track.
- Runners are tested to 100,000 cycles (equivalent to around 25 years of average use).
- Adjustable door protrusion from the pocket.
- Jamb kit made from finger-jointed timber, unfinished, ready to paint or stain.
- Door guide slots into a channel on the underside of the door, ensuring smooth sliding even if the door warps.
- 15-year guarantee on the complete steel pocket system and runners.
Dimensions & Specifications
| Door Panel Size | Pocket Frame Size |
|---|---|
| 610 x 1981 mm | 1273 x 2056 mm |
| 686 x 1981 mm | 1449 x 2056 mm |
Installation Instructions
The door jambs are available in two size options: 100mm or 125mm. If using 3" studwork, you will require 100mm jambs to achieve a finished wall thickness of 100mm with 12.5mm plasterboard. For 4" studwork, use 125mm jambs for an overall wall thickness of 125mm with 125mm plasterboard.
There is no bottom track or threshold strip; as with all pocket door systems, the single pocket door frame is top-hung from a track. Inside the track, runners attached to the top of the door via a bracket ensure that your flooring can continue through the opening undisturbed.
Technical Specifications
- Material: Galvanised steel frame
- Thickness: 35mm/40mm
- Door guide: Integrated channel for smooth operation
- Durability: Tested for 100,000 cycles
- Warranty: 15 years on the complete system
FAQ
Q: Can the door be painted or stained?
A: Yes, the jamb kit is made from finger-jointed timber and is ready to paint or stain.
Q: Is a bottom track required?
A: No, this pocket door system does not require a bottom track or threshold strip.
Q: What is the warranty period?
A: There is a 15-year guarantee on the complete steel pocket system and runners.
