Premium 3 Panel Pocket Door System with Galvanised Steel Frame and Adjustable Features for Seamless Installation
Premium 3 Panel Pocket Door System with Galvanised Steel Frame and Adjustable Features for Seamless Installation
Product Overview
This Premium Pocket Door System is supplied complete with a 3 Panel Door. This system allows you to slide the door straight into a discreet pocket hidden within the cavity. The pocket frame is constructed from galvanised steel and is supplied complete with the track and fixings. The cassette system comes with a comprehensive timber lining kit (jambs) to ensure a perfect installation.
Jamb Options
The door jambs are available in two size options:
- 100mm for 3" studwork, providing a finished wall thickness of 100mm when finished with 12.5mm plasterboard.
- 125mm for 4" studwork, resulting in an overall wall thickness of 125mm when using 125mm plasterboard.
Design Features
There is no bottom track or threshold strip; like all our pocket door systems, this single pocket door frame is top hung from a track. Inside the track, runners are attached to the top of the door via a bracket, which allows for an uninterrupted floor space. Accessories such as soft door closers, flush door pulls, and bathroom locks can be purchased separately.
Key Features
- Complete with Internal Door
- 35mm thick door supplied primed
- Strong galvanised steel frame with a quick-click design for easy assembly
- Runners tested to 100,000 cycles (approximately 25 years of average use)
- Adjustable to determine how far the door protrudes from the pocket
- Jamb kit made from finger-jointed unfinished wood, ready to paint or stain
- Door guide slots into a channel on the underside of the door, ensuring smooth operation even if the door warps
- 15-year guarantee on the complete steel pocket system and runners
Dimensions & Specifications
| Door Panel Size | Pocket Frame Size (Width x Height) |
|---|---|
| 686 x 1981 mm | 1449 x 2056 mm |
| 762 x 1981 mm | 1625 x 2056 mm |
| 838 x 1981 mm | 1701 x 2056 mm |
Additional Information
Our Pocket Door Systems can also be supplied in made-to-measure options. Please inquire for more information on bespoke options.
Please note that you may receive two deliveries: the frames are usually dispatched within 24/48 hours, and the doors will be delivered within 3-5 working days.
FAQ
- How does the pocket door system work? The system allows the door to slide into a pocket within the wall, eliminating the need for a bottom track.
- What is the guarantee on the system? The complete steel pocket system and runners come with a 15-year guarantee.
- Can the size of the door be customized? Yes, the pocket door systems can be made to measure based on your specifications.
