Product Overview
This Premium Pocket Door System is supplied complete with a clear glazed internal door, allowing you to slide the door straight into a discreet pocket hidden within the cavity. The pocket frame is constructed from robust galvanised steel and includes the track and fixings necessary for installation. Additionally, the cassette system comes with a comprehensive timber lining kit (jambs) to ensure a perfect finish.
Features and Benefits
- Complete with Clear Glazed Internal Door
- Compatible with 35mm/40mm thick doors
- Strong galvanised steel frame with a quick-click assembly
- Runners tested for up to 100,000 cycles (approximately 25 years of average use)
- Adjustable door protrusion from the pocket
- Finger-jointed unfinished jamb kit ready to paint or stain
- Invisible door guide to ensure smooth operation even if the door warps
- 15-year guarantee on the complete steel pocket system and runners
Dimensions & Specifications
| Imperial Door Sizes | Pocket Frame Dimensions (Width x Height) |
|---|---|
| 610 x 1981 Door Panel | 1273 x 2056 mm |
| 686 x 1981 Door Panel | 1449 x 2056 mm |
| 762 x 1981 Door Panel | 1625 x 2056 mm |
| 838 x 1981 Door Panel | 1701 x 2056 mm |
| Metric Door Sizes | Pocket Frame Dimensions (Width x Height) |
|---|---|
| 726 x 2040 Door Panel | 1600 x 2108 mm |
| 826 x 2040 Door Panel | 1800 x 2108 mm |
Technical Specifications
The pocket door system does not include a bottom track or threshold strip, as the single pocket door frame is top hung from a track. Runners are attached to the top of the door via a bracket, allowing flooring to continue through the opening undisturbed. Accessories such as soft door closers, flush door pulls, and bathroom locks can be purchased separately.
FAQ
- What thickness doors are compatible with this system? The system supports 35mm and 40mm thick doors.
- What is the warranty on this pocket door system? There is a 15-year guarantee on the complete steel pocket system and runners.
- Can I customize the dimensions of the pocket door system? Yes, made-to-measure options are available for bespoke requirements.
