Premium Fire Rated Pocket Door System for 30-Minute Fire Doors with Adjustable Jamb Kit and Maintenance-Free Track

Product Overview

This fire-rated pocket door frame is designed to accommodate any 30-minute fire-rated door (FD30). It features all the benefits of a standard pocket door system, enhanced with a specially designed jamb kit made from Koto hardwood. This system is supplied unfinished and pre-treated with intumescent primer for added safety.

Key Features

• For use with 44mm FD30 rated fire doors
• Maintenance-free track and runners
• Fully adjustable front and rear doorstop
• Runners tested to 100,000 cycles (approximately 25 years of average use)
• Anti-warp door profile
• 100mm jambs (wall thickness)
• Self-centering floor guide
• 15-year guarantee on the complete steel pocket system and runners
• Fully tested and approved by International Fire Consultants PAR/10057/01
• Compatible with a self-closing mechanism
• Compatible with BIAS Anti Slam Soft Close Mechanism

Accessories

• A fully approved self-closing mechanism is available. Check with a Building Inspector to determine if your application requires a self-closer before ordering.

Dimensions & Specifications

Made for use with standard UK door sizes, this system can also be supplied in made-to-measure options. Contact us for more information on bespoke options.

Technical Specifications

• Material: Koto hardwood, pre-treated with intumescent primer
• Jamb Width: 100mm
• Door Thickness: 44mm
• Guarantee: 15 years
• Compatibility: Self-closing mechanism, BIAS Anti Slam Soft Close Mechanism

FAQs

• What is the fire rating of this door system? It is designed for use with 30-minute fire-rated doors (FD30).
• How durable are the runners? The runners are tested for 100,000 cycles, equivalent to about 25 years of average use.
• Can this door system be customized? Yes, it can be supplied in made-to-measure options for specific requirements.
