Premium Fire Rated Pocket Door Frame System with Adjustable Jambs and Self-Centering Guide
Single Pocket Door System 610 x 1981mm
£1,498.01
Skip to product information
Premium Fire Rated Pocket Door Frame System with Adjustable Jambs and Self-Centering Guide
£1,498.01
Product Overview
This premium fire-rated pocket door frame system is designed for use with any 30-minute fire-rated door (FD30). It incorporates the benefits of a standard pocket door system while featuring a specially designed jamb kit made from a durable hardwood known as Pterygota, commonly referred to as Koto. This frame is supplied unfinished and pre-treated with intumescent primer for enhanced fire resistance.
- Compatible with 44mm FD30-rated fire doors (not included).
- Maintenance-free track and runners for hassle-free operation.
- Fully adjustable front and rear doorstop for precise positioning.
- Runners tested for 100,000 cycles, equivalent to approximately 25 years of average use.
- Anti-warp door profile ensures longevity and stability.
- 100mm jambs suitable for wall thickness.
- Self-centering floor guide for optimal functionality.
- 15-year guarantee on the complete pocket system and runners.
- Fully tested and approved by International Fire Consultants.
- Compatible with self-closing mechanisms and BIAS Anti Slam Soft Close Mechanism.
- Available with white or brown intumescent seals.
- Door jambs require finishing with fire-retardant paint.
Optional Accessories
- Back of the door self-closer - a clever device that allows the door to close automatically without manual input.
- Adjustable closing speed for tailored operation.
Dimensions & Specifications
| Door Panel Size (Width x Height) | Pocket Frame Size (Width x Height) |
|---|---|
| 610 x 1981 mm | 1279 x 2061 mm |
| 686 x 1981 mm | 1455 x 2061 mm |
| 762 x 1981 mm | 1631 x 2061 mm |
| 838 x 1981 mm | 1701 x 2061 mm |
| 915 x 1981 mm | 1781 x 2061 mm |
Technical Specifications
- Material: Pterygota hardwood, intumescent primer pre-treatment.
- Jamb Size: 100mm.
- Fire Rating: 30 minutes (FD30).
- Guarantee: 15 years on the complete system.
FAQs
-
Q: Can this system be installed retrospectively?
A: Yes, the system allows for retrospective installation. -
Q: What is the closing speed adjustment feature?
A: The system allows you to adjust the closing speed of the door for tailored operation. -
Q: Is the self-closing mechanism mandatory for installation?
A: It is advisable to refer to the Field of Application Report and consult with your Building Inspector for requirements.
