Premium External Glazed Fire Door Set with 30 Minutes Fire Resistance and Multipoint Locking System
Premium External Glazed Fire Door Set with 30 Minutes Fire Resistance and Multipoint Locking System
Product Overview
This Premium External Glazed Fire Door Set is designed to perform and meet the rigorous demands of fire safety. With a solid-core construction, this door set offers unparalleled durability and security, coupled with 30 minutes of fire resistance tested to BS 476 part 22 and resistance to smoke passage tested to BS 476 part 31:1.
Our fire door sets are available in 30 and 60-minute timber options that bear relevant certifications, ensuring compliance with mandatory safety requirements while providing excellent thermal efficiency. This door set is supplied complete with a frame and ironmongery, ready to hang into your opening.
Configurations
If the fire door is used as the main external door and requires a letter plate, please select the "secure by design" option to comply with the latest regulations.
Non-Secured By Design Features
- White PVC Fire-check Frame
- Multipoint Locking System
- Overhead Closer Fitted as Standard
- Fire Rated Hinges
- Choice of 11 Colours for the External Face
- White Internal Face
- Door Handle Included - Choose from Silver or Brass finish
Secured By Design Doorsets Features
- Door Leaf Type: Solid timber core
- Choice of 11 Colours for the External Face
- Outer Frame Type: White PVCu extruded
- Intumescent Seals: Applied to the top and bottom of the door leaf, to the internal rebate and outside of the outer frame, and selected components
- Threshold: Slimline with fire retardant seal ·Low Mobility compliant
- Timber Cill options available
- Hinges: 4 Nico Lift-off hinges
- Lock: 4-point autofire locking system with adjustable keeps
- Cylinder: 3* Key-thumb turn cylinder, with 3 keys
- Handle: Lever-lever
- Viewer: 180 degrees fire-rated viewer (optional)
- Knocker: Urn knocker (optional)
- Letter plate: Fire-rated TS008 Letter plate with integral cowl (optional)
- Closer: Rutland TS5204 overhead closer
- Security Chain: Hook type (optional)
- Hardware finish options: Gold or Silver
Certification and Accreditations
- Fire tested to: BS 476: Part 20/22:1987, EN 1634-1: 2014 + A1:2018. All door sets are bi-directionally tested.
- Smoke Control test: EN 1634-3: 2004
- CE Marking: External ·Yes
- PAS 24 / Secured By Design: PAS 24 2016 specification and Secured by Design accredited
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Fire Resistance | 30 minutes |
FAQs
What is the fire resistance rating of this door?
This door has a fire resistance rating of 30 minutes.
Can I choose a color for the external face?
Yes, there is a choice of 11 colors available for the external face.
What type of locking system is included?
The door features a multipoint locking system for enhanced security.
