Premium External Fire Door Set with Sidelight - 30 Minute Fire Resistance, Multipoint Locking System and Customizable Colors
Premium External Fire Door Set with Sidelight - 30 Minute Fire Resistance, Multipoint Locking System and Customizable Colors
Product Overview
This Premium External Fire Door Set with Sidelight is designed to meet the rigorous demands of fire safety while providing exceptional durability and security. Featuring a solid-core construction, this door set is engineered for 30-minute fire resistance in compliance with BS 476 part 22, along with smoke resistance to BS 476 part 31:1.
Features
Our versatile, maintenance-free door sets not only meet mandatory fire safety requirements but also offer great thermal efficiency. The set comes complete with a frame and ironmongery, making it ready to hang into your opening.
When used as the main external door, if a letter plate is required, selecting the 'secure by design' option is essential for compliance with the latest regulations.
Non-Secured By Design Includes:
- White PVC Fire-check Frame
- Multipoint Locking System
- Overhead Closer Fitted as Standard
- Fire Rated Hinges
- Choice of 11 Colours for the External Face
- White Internal Face
- Door Handle Included - Choose from Silver or Brass finish
Secured by Design Doorsets Include:
- Door Leaf Type: Solid timber core
- Choice of 11 Colours for the External Face
- Outer Frame Type: White PVCu extruded
- Intumescent Seals: Applied to the top and bottom of the door leaf, to the internal rebate and outside of the outer frame, and selected components
- Threshold: Slimline with fire retardant seal ·Low Mobility compliant
- Timber Cill options
- Timber-like grained
- Hinges: 4 Nico Lift-off hinges
- Lock: ERA Surefire 4 point autofire locking system with adjustable keeps
- Cylinder: 3* Key-thumb turn cylinder, with 3 keys
- Handle: Lever-lever
- Viewer: 180 degrees fire-rated viewer (optional)
- Knocker: Urn knocker (optional)
- Letter Plate: Fire-rated TS008 Letter plate with integral cowl (optional)
- Closer: Rutland TS5204 overhead closer
- Security Chain: Hook type (optional)
- Hardware Finish: Gold or Silver
Sidelight Features
- PVC framed glazed sidelight
- Fire rated glass
- Available with Clear or Obscure (Stippolyte) glass
- Sidelights available in three widths: 250mm, 400mm, 600mm
Certification and Accreditations
- Fire tested to: BS 476: Part 20/22:1987 EN 1634-1: 2014 + A1:2018. All door sets are bi-directionally tested
- Smoke Control Test: EN 1634-3
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Fire Resistance | 30 Minutes |
FAQ
What is the fire rating of this door set?
The door set is rated for 30 minutes of fire resistance.
Can I customize the color of the door?
Yes, you can choose from 11 different colors for the external face.
Is the sidelight included?
Yes, the sidelight comes with the door set and is available in multiple widths.
